UHMW suction box cover plate
material of UHMW suction box cover plate :
MATERIAL: CERAMIC WITH UHMWPE, 5.0 MILLION VOLUME WITH STRONG HARDNESS AND QUALITY.
COLOR: BLACK
SIZE (L X W X T): 3700 MM X 280 MM X 50 MM
WORKING AREA: 3045 MM X 220 MM
CUTTING DESIGN: AS PER BUYER’S DESIGN
Application of UHMW suction box cover plate :
At machine speeds of up to approx. 800 m/min. Depending on the position even at higher speeds.
Assembly of LIJIU UHMW suction box cover plate :
UHMWPE dewatering elements have a high level of thermal expansion. They must therefore be installed in such a way that enables the strips or covers to expand without restriction (T-bars, corner strips, dovetail guides, screws in elongated holes). The base frame support must have a grid of approx. 250 mm to ensure flawless functionality for our covers. This support must extend to the underside of the cover to ensure it has a flat installation surface.
Let us see why choose UHMWPE material to be used for suction box ?
UHMWPE Suction tops ,UHMWPE Dewatering elements ,uhmwpe suction box cover
Key Features and Benefits of UHMWPE Suction tops Plus:
Impact strength – it is virtually unbreakable
Light weight – easy to handle without special equipment
Electrical insulation – it is a good insulator
Weatherproof – it doesn’t absorb water
Chemical resistance – resists corrosive chemicals (Sulphuric Acid, Caustic Soda)
Abrasion resistance – rated better than carbon steel for sliding abrasion applications
