Yellow UHMWPE Fender Facing pads ,UHMWPE Fender pads ,UHMWPE Fender plate ,UHMWPE Plate ,UHMWPE Fender
Yellow UHMWPE Fender pads ,Black UHMWPE Fender pads ,Blue UHMWPE Fender pads ,Grey UHMWPE Fender pads is all available here .
UHMW-PE Fender pads and fenders are produced by a sintering process either from virgin or from reclaimed material (aprox. 70% reclaimed +30% virgin material - also named double-sintered or blended UHMW-PE).
UHMW-PE (UltraHighMolecularWeight-PolyEthylene) combines highest strength with wear resistance and consequently provides the best durabilty of all available Polyethylene products.
Advantages are:
● Very high impact strength
● Very low friction coefficient
● Very high abrasion resistance
● UV + Ozone resistant
● Non-conducting (optional)
● 100% recycable, non-rottening
● Cut to size sheet ,all size is available with us
● Standard colour :Black ,Yellow ,Blue ,Green ,Red,White ,other colour is available upon request .
The application is as follows:
● low resistance sliding plates on fender panels
● low resistance slinding panels for bridge and pier protection
● corner protection for offshore structures, berths and other marine facilities
Specification (For special requirements ,please contact us):
| Item | Test method | Unit | UHMWPE 1000-V | UHMWPE 1000-DS |
| Density | ISO1183-1 | g/cm3 | 0.93-0.95 | 0.95-0.96 |
| Yield Strength | ASTM D-638 | N/mm2 | 15-22 | 15-22 |
| Breaking Elongation | ISO527 | % | undefined200% | undefined100% |
| Impact strength | ISO179 | Kj/m2 | 130-170 | 90-130 |
| Abrasion | ISO15527 | Steel=100 | 80-110 | 110-130 |
| Shore Hardness | ISO 868 | Shore D | 63-64 | 63-67 |
| Friction Coefficient(Static state) | ASTM D-1894 | Unitless | undefined0.2 | undefined0.2 |
| Operating temperature | - | ℃ | -80 to +80 | -80 to +80 |
UHMW-PE Flat Fender pad ,UHMW-PE Corner Fender pad ,UHMW-PE Edge Fender pad all is available
For special drawing and properties of UHMW-PE Fender facings /UHMW-PE Fender pad ,please contact us by our email amily.tong@abosn.com
Abosn UHMWPE Fender pads have been widely sold to all over the world like America ,Europe ,Australia ,Asia ,Africa ,Southeast Asia and so on .
Competitive price and good quality make our UHMWPE Fender pads very popular among customers .
