Green UHMWPE Fender plate ,UHMWPE Fender pads ,Green UHMWPE Pads ,Green UHMWPE Sheet ,UHMWPE Fender pads ,UHMWPE Fender ,UHMWPE Board
Abosn have supplied the world largest Marine fender company for nearly 10 years and our UHMWPE Fender pads have been exported to all over the world .
UHMW-PE Fender pads and fenders are produced by a sintering process either from virgin or from reclaimed material (aprox. 70% reclaimed +30% virgin material - also named double-sintered or blended UHMW-PE).
UHMW-PE (UltraHighMolecularWeight-PolyEthylene) combines highest strength with wear resistance and consequently provides the best durabilty of all available Polyethylene products.
The UHMWPE FENDER PAD application is as follows:
● low resistance sliding plates on fender panels
● low resistance slinding panels for bridge and pier protection
● corner protection for offshore structures, berths and other marine facilities
The UHMWPE FENDER PAD Advantages are:
● Very high impact strength
● Very low friction coefficient
● Very high abrasion resistance
● UV + Ozone resistant
● Non-conducting (optional)
● 100% recycable, non-rottening
● Cut to size sheet ,all size is available with us
● Standard colour :Black ,Yellow ,Blue ,Green ,Red,White ,other colour is available upon request .
Here we also have UHMWPE Corner pads ,UHMWPE Edge pads ,UHMWPE Flate pads .
Bridgestone UHMWPE Fender pads ,Trelleborg UHMWPE FENDER PADS AND OTHER KINDS OF FENDER PADS FOR YOUR REFERENCE .
Specification (For special requirements ,please contact us):
| Item | Test method | Unit | UHMWPE 1000-V | UHMWPE 1000-DS |
| Density | ISO1183-1 | g/cm3 | 0.93-0.95 | 0.95-0.96 |
| Yield Strength | ASTM D-638 | N/mm2 | 15-22 | 15-22 |
| Breaking Elongation | ISO527 | % | undefined200% | undefined100% |
| Impact strength | ISO179 | Kj/m2 | 130-170 | 90-130 |
| Abrasion | ISO15527 | Steel=100 | 80-110 | 110-130 |
| Shore Hardness | ISO 868 | Shore D | 63-64 | 63-67 |
| Friction Coefficient(Static state) | ASTM D-1894 | Unitless | undefined0.2 | undefined0.2 |
| Operating temperature | - | ℃ | -80 to +80 | -80 to +80 |
